This current can be regulated with the 500ohm trimmer resistor. this is a class B amplifier, this means, that a current must flow through the end transistors, even if there is no signal on the input. capacitor C2 regulates the higher frequencies (treble), as the capacitance grows, the higher frequencies are getting quiter. Some comments: - capacitor C1 regulates the low frequencies (bass), as the capacitance grows, the low frequncies are getting louder. The and transistors can be any NPN type power transistor, but do not use Darlington types. As you can see, in this design the components have a big tolerance, so you can build it almost of the components, which you find at home.
The maximal input voltage is around 0.8 - 1V. The optimal supply voltage is around 50V, but this amp work from 30 to 60V. 2N3055 Power Amplifier Simple and low cost. washing machines, refrigerators and air-condition), set-top-boxes, LCD/LED monitors and general purpose power supply up to a maximum output power of 43W.P1.
To further reduce BOM count and cost of an non-isolated flyback or buck design, an integrated error amplifier is integrated to allow a direct feedback from the primary output with minimal components and complexity.ĥ th generation fixed frequency CoolSET™ is targeted for SMPS applications such as auxiliary power supply for home appliances (e.g. In addition, for low AC line input operation, CCM (Continuous Current Mode) operation have been implemented to achieve lower conduction losses thereby achieving a higher efficiency to meet international regulatory standards. To further enhance the efficiency performance, frequency reduction operation have been implemented to achieve higher efficiency with lower switching frequency at mid and light load condition. Infineon latest 5 th generation of fixed frequency AC-DC integrated power stages offers high performance with the integration of the renowned 700V and 800V, and 950V CoolMOS™ P7 family in both DIP-7 and DSO-12 packages.
